BOTH AMF AND SYNCHRONIZING
SAME UNIT FOR ALL FUNCTIONS
REMOTE ACCESS
MULTI-PROTOCOL
FLEXIBLE WITH PLUG-IN MODULES
AUTO LEARNING

FEATURES

Diesel and gas genset support
400Hz operation support
400 event logs, full snapshot
All parameters front panel editable
3 level configuration password
128x64 graphical LCD display
Downloadable languages
Waveform display of V & I
Harmonic analysis of V & I
Synchroscope & synchro-check
Allows closed transfers
16Amp MCB & GCB outputs
8 configurable digital inputs
Expandable up to 40 inputs
8 configurable digital outputs
Expandable up to 40 outputs
7 configurable analog inputs
Both CANBUS-J1939 & MPU
3 configurable service alarms
Multiple topologies
6xCT, true mains metering
Supports up to 48 gensets
Automatic learning/self adjust
Direct governor & AVR control
Voltage and phase matching
kW & kVAr load sharing
True soft transfer in both ways
PLC functions
Peak Lopping / peak shaving
Mains de-coupling protection
R.O.C.O.F protection
Vector shift protection
Reverse power protection
Over/under freq. Protection
Over/under voltage protection
Smart load management
Smart genset sequencing
Run/stop priority support
Equal aging of gensets
Base load (power transfer)
Unmanaged distributed power
export support
AVR & GOV droop support
Dead bus sensing
Multiple automatic exerciser
Weekly operation schedule
Dual mutual standby with
equal aging of gensets
Manual “speed fine adjust” on
selected ECUs
Automatic fuel pump control
Disable protections feature
Excess power protection
Overload IDMT protection
Load shedding, dummy load
Multiple load management
Unbalance current protection
Unbalance voltage protection
Fuel filling & fuel theft alarms
Contactor & MCB drive
Battery back-up real time clock
Idle speed control
Battery charge run enabled
Combat mode support
Multiple nominal conditions
4 quadrant genset power counters
Mains power counters
Fuel filling counter
Fuel consumption counter
Modem & ethernet diagnostics
Configurable through USB,
RS-485, Ethernet and GPRS
Free configuration program
Allows SMS controls
Ready for central monitoring
ethernet & GPRS
Mobile genset support
Automatic GSM geo-location
GPS connectivity (USB&RS232)
Dynamic DNS support
Easy USB firmware upgrade
IP65 rating with standard gasket
